Digital Telemetry Receiver



DESCRIPTION

Digilogic telemetry receiver design is highly flexible and provides comprehensive link support for satellite and flight test ground station applications in a fully integrated package. Our telemetry receiver design features FPGA based signal processing and software defined radio technology in the form of digital telemetry receivers, waveform & signal processors. A variety of configurations (Single, Dual) and waveforms (AM, FM, PM, BPSK, QPSK & SOQPSK) are available with standard data rates from 40 Mbps down to 100 kbps. It also supports Automatic Gain Control, AM Tracking, Diversity Combining, Equalization, Demodulation of PCM-FM & SOQPSK-TG, Bit Synchronization, Frame Synchronization, LDPC and Convolutional Decoding, and Telemetry Over IP (TMoIP) as per IRIG Standard.



Telemetry Receiver system also has an in-built test signal generator, to test the performance of complete receiver chain without any external source. The system also provides access to downconverted IF signals, Bit sync outputs, Data & Clock signals for analysis with any external systems. All these I/Os are available through connectors on rear side of the unit. As the system design is indigenous & FPGA based, any kind of customization needed towards any new modulation schemes can be incorporated in the system.



FEATURES

Dual Channel RF (S-band) and IF Receiver

Data rates up to 40 Mbps

Eye pattern diagram

Spectrum Display

I/Q constellation diagram

Trellis Detection for improved performance

Diversity Combiner and Equalizer

Convolutional and LDPC Decoding

Decryption, Frame Synchronization

AFC, AM Demodulation for Tracking

Telemetry over IP (TMoIP ) Support

Supports display over ethernet

Customizable for various other modulation schemes and data rates



APPLICATIONS

Telemetry tracking and reception

Aircraft and UAVs flight testing

Low Earth Orbit (LEO) satellite tracking and data reception



SPECIFICATION:
